ETALON SECURITY Etalon New Tool Ltd.
Supply Voltage 12 to 30 Vdc normal
Supply Current 5.5mA in all operational states
Supply Current 13.5mA in fast commissioning
Environmental Specifications
Temperature -10°C to +55°C
Humidity 10 to 95% RH Non-condensing
Protection Index IP65 when suitably mounted and terminated
Beam Head
180mmH x 155mmW x137mmD Weight 1.1Kg
70KIT140 Mid-Range Reflector
293mmH x293mmW x 5mmD Weight 0.8Kg
140KIT160 Long Range Reflector
394mmH x 394mmW x 5mmD Weight 1.8Kg
Adapter
270mmH x 250mmW x 5mmD Weight 0.6g
(mounts the Beam Head onto unistrut)
Optical Wavelength 870nm
Maximum Angular Alignment ±5°
Maximum Angular Misalignment
(static not auto-aligning) Beam Head ±0.4° Reflector ±2°
- Electrical Specifications
-
Supply Voltage 12 to 30 Vdc normal
Supply Current 5.5mA in all operational states
Supply Current 13.5mA in fast commissioning
Environmental Specifications
Temperature -10°C to +55°C
Humidity 10 to 95% RH Non-condensing
Protection Index IP65 when suitably mounted and terminated
- Mechanical Specifications
-
Beam Head
180mmH x 155mmW x137mmD Weight 1.1Kg
70KIT140 Mid-Range Reflector
293mmH x293mmW x 5mmD Weight 0.8Kg
140KIT160 Long Range Reflector
394mmH x 394mmW x 5mmD Weight 1.8Kg
Adapter
270mmH x 250mmW x 5mmD Weight 0.6g
(mounts the Beam Head onto unistrut)
- Optical Specifications
-
Optical Wavelength 870nm
Maximum Angular Alignment ±5°
Maximum Angular Misalignment
(static not auto-aligning) Beam Head ±0.4° Reflector ±2°
- USER GUIDE
